BD9582F-E2 - ROHM Semiconductor

BD9582F-E2 Details

• Manufacturer Part Number:

  BD9582F-E2

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  6.20 X 5 MM, 1.71 MM HEIGHT, ROHS COMPLIANT, SOP-8

• HTS Code:

  8542.39.00.01

• Manufacturer:

  ROHM Semiconductor

• YTEOL:

  0

• Analog IC - Other Type:

  ANALOG CIRCUIT

• JESD-30 Code:

  R-PDSO-G8

• Length:

  5 mm

• Number of Functions:

  1

• Number of Terminals:

  8

• Operating Temperature-Max:

  95 °C

• Operating Temperature-Min:

  -20 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  SOP

• Package Equivalence Code:

  SOP8,.25

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  1.71 mm

• Supply Current-Max (Isup):

  0.52 mA

• Supply Voltage-Max (Vsup):

  22 V

• Supply Voltage-Min (Vsup):

  12 V

• Supply Voltage-Nom (Vsup):

  12 V

• Surface Mount:

  YES

• Temperature Grade:

  OTHER

• Terminal Form:

  GULL WING

• Terminal Pitch:

  1.27 mm

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Width:

  4.4 mm
