BFR840L3RHESD - Infineon

BFR840L3RHESD Details

• Manufacturer Part Number:

  BFR840L3RHESD

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  TSLP-3-9, 3 PIN

• ECCN Code:

  EAR99

• Manufacturer:

  Infineon Technologies AG

• YTEOL:

  0

• Case Connection:

  EMITTER

• Collector Current-Max (IC):

  0.035 A

• Collector-Base Capacitance-Max:

  0.052 pF

• Collector-Emitter Voltage-Max:

  2.25 V

• Configuration:

  SINGLE

• DC Current Gain-Min (hFE):

  150

• Highest Frequency Band:

  X BAND

• JESD-30 Code:

  R-PBCC-N3

• JESD-609 Code:

  e4

• Moisture Sensitivity Level:

  1

• Number of Elements:

  1

• Number of Terminals:

  3

• Operating Temperature-Max:

  150 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  CHIP CARRIER

• Packing Method:

  TR

• Polarity/Channel Type:

  NPN

• Power Dissipation-Max (Abs):

  0.075 W

• Reference Standard:

  AEC-Q101

• Surface Mount:

  YES

• Terminal Finish:

  Gold (Au)

• Terminal Form:

  NO LEAD

• Terminal Position:

  BOTTOM

• Transistor Application:

  AMPLIFIER

• Transistor Element Material:

  SILICON GERMANIUM

• Transition Frequency-Nom (fT):

  75000 MHz
