ROHM recommends a thermal pad on the bottom of the package, connected to a large copper area on the PCB to dissipate heat efficiently. A minimum of 2oz copper thickness is recommended, and the thermal pad should be connected to a ground plane to reduce thermal resistance.
To ensure stable operation with a single power supply, ROHM recommends decoupling capacitors (e.g., 10uF and 100nF) between the power supply pins (VCC and GND) and the device. Additionally, a 1kΩ resistor in series with the input signal can help stabilize the operation.
Although the datasheet specifies a maximum input voltage of 5.5V, ROHM recommends limiting the input voltage to 5V or less to ensure reliable operation and prevent damage to the device.
ROHM recommends implementing ESD protection measures, such as adding ESD diodes (e.g., 1.5KE6.8A) between the input pins and the power supply pins, and using an ESD-resistant PCB design to prevent damage from electrostatic discharge.
Although the datasheet specifies an operating temperature range of -40°C to 85°C, ROHM recommends operating the device within a range of 0°C to 70°C for optimal performance and reliability.
Trust Checks
This model has been provided by an expert contributor.
Expert Contribution
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
BH7649KS2 Overview
Use the download button to access the BH7649KS2 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like BH764,
or try a keyword search, such as Other Consumer ICs
