BM2P121XH-Z - ROHM Semiconductor

Description: Non-isolated Type PWM DC/DC Converter IC Built-in Switching MOSFET

Download BM2P121XH-Z Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
BM2P121XH-Z - ROHM Semiconductor PCB footprint - Other - Other - DIP_7K
click to zoom
3D Models
BM2P121XH-Z - ROHM Semiconductor  - 3D model - Other - DIP_7K
click to zoom

BM2P121XH-Z Details

  • Manufacturer Part Number:

    BM2P121XH-Z

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    DIP-7

  • Country Of Origin:

    Philippines

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Date Of Intro:

    2020-07-06

  • Manufacturer:

    ROHM Semiconductor

  • Analog IC - Other Type:

    SWITCHING REGULATOR

  • Control Mode:

    CURRENT-MODE

  • Control Technique:

    PULSE WIDTH MODULATION

  • Input Voltage-Max:

    12.96 V

  • Input Voltage-Min:

    9.5 V

  • JESD-30 Code:

    R-PDIP-T7

  • Length:

    9.27 mm

  • Number of Functions:

    1

  • Number of Terminals:

    7

  • Operating Temperature-Max:

    105 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    DIP

  • Package Equivalence Code:

    DIP7,.3

  • Package Shape:

    RECTANGULAR

  • Package Style:

    IN-LINE

  • Seated Height-Max:

    5.33 mm

  • Supply Current-Max (Isup):

    1.15 mA

  • Surface Mount:

    NO

  • Switching Frequency-Max:

    70 kHz

  • Terminal Form:

    THROUGH-HOLE

  • Terminal Pitch:

    2.54 mm

  • Terminal Position:

    DUAL

  • Width:

    7.62 mm

BM2P121XH-Z Frequently Asked Questions (FAQs)

  • ROHM recommends a thermal pad on the bottom of the package, connected to a large copper area on the PCB to dissipate heat efficiently. A minimum of 2oz copper thickness and a thermal relief pattern are also recommended.
  • To ensure stable operation with a high-impedance input signal, add a 1kΩ to 10kΩ pull-down resistor at the input pin to prevent oscillation and improve noise immunity.
  • The maximum allowed voltage on the EN (enable) pin is 6V, exceeding which may cause damage to the device. It's recommended to keep the EN pin voltage within the specified range of 0V to 5.5V.
  • While the BM2P121XH-Z is rated for operation up to 105°C, it's essential to consider the derating curve for power dissipation and ensure the device is properly heat-sinked to prevent thermal shutdown or damage.
  • To minimize EMI, use a ground plane on the PCB, keep signal traces short and away from the power supply, and add a 10nF to 100nF decoupling capacitor between the VIN pin and GND. Additionally, consider using a shielded inductor and a common-mode choke filter.
