BM2P129TF-E2 - ROHM Semiconductor

Description: PWM type DC/DC converter IC Integrated Switching MOSFET for non-Isolated type

Download BM2P129TF-E2 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
BM2P129TF-E2 - ROHM Semiconductor PCB footprint - Small Outline Packages - Small Outline Packages - SOP8 (1)
click to zoom
3D Models
BM2P129TF-E2 - ROHM Semiconductor  - 3D model - Small Outline Packages - SOP8 (1)
click to zoom

BM2P129TF-E2 Details

  • Manufacturer Part Number:

    BM2P129TF-E2

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    SOP-8

  • Country Of Origin:

    Philippines

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Date Of Intro:

    2017-03-01

  • Manufacturer:

    ROHM Semiconductor

  • YTEOL:

    6

  • Analog IC - Other Type:

    SWITCHING REGULATOR

  • Control Mode:

    CURRENT-MODE

  • Control Technique:

    PULSE WIDTH MODULATION

  • Input Voltage-Max:

    12.98 V

  • Input Voltage-Min:

    8 V

  • JESD-30 Code:

    R-PDSO-G8

  • Length:

    5 mm

  • Number of Functions:

    1

  • Number of Terminals:

    8

  • Operating Temperature-Max:

    105 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    SOP

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE

  • Peak Reflow Temperature (Cel):

    NOT SPECIFIED

  • Seated Height-Max:

    1.71 mm

  • Surface Mount:

    YES

  • Switching Frequency-Max:

    100 kHz

  • Temperature Grade:

    INDUSTRIAL

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    1.27 mm

  • Terminal Position:

    DUAL

  • Time@Peak Reflow Temperature-Max (s):

    NOT SPECIFIED

  • Width:

    4.4 mm

BM2P129TF-E2 Frequently Asked Questions (FAQs)

  • The recommended operating temperature range for BM2P129TF-E2 is -40°C to 125°C.
  • To ensure the stability of the output voltage, it is recommended to use a ceramic capacitor with a capacitance value of 1uF or more between the VOUT and GND pins, and to keep the input voltage within the specified range.
  • The maximum input voltage that BM2P129TF-E2 can handle is 36V. Exceeding this voltage may cause damage to the device.
  • The output voltage of BM2P129TF-E2 can be calculated using the formula: VOUT = 0.8V x (1 + R1/R2), where R1 and R2 are the resistors connected between the VOUT, ADJ, and GND pins.
  • The quiescent current of BM2P129TF-E2 is typically around 50uA, but it can vary depending on the input voltage and output load conditions.
