BNC5-J-P-GN-ST-TH2D - SAMTEC

BNC5-J-P-GN-ST-TH2D Details

• Manufacturer Part Number:

  BNC5-J-P-GN-ST-TH2D

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  ROHS COMPLIANT

• Country Of Origin:

  Taiwan

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.10

• Manufacturer:

  Samtec Inc

• YTEOL:

  8

• Body Depth:

  1.142 inch

• Body Diameter:

  0.38 inch

• Body/Shell Style:

  JACK

• Characteristic Impedance:

  50 Ω

• Connector Type:

  RF BNC CONNECTOR

• Contact Finish Mating:

  GOLD (10) OVER NICKEL (50)

• Contact Gender:

  FEMALE

• Contact Material:

  PHOSPHOR BRONZE

• Contact Style:

  COAX

• Coupling Type:

  BAYONET

• DIN Conformance:

  NO

• Filter Feature:

  NO

• IEC Conformance:

  NO

• Insulator Material:

  POLYTETRAFLUOROETHYLENE

• MIL Conformance:

  NO

• Mounting Option 1:

  LOCKING

• Mounting Style:

  STRAIGHT

• Mounting Type:

  BOARD

• Number of Ports:

  1

• Operating Frequency-Max:

  4 GHz

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -65 °C

• Option:

  GENERAL PURPOSE

• Panel Mount:

  NO

• Shell Material:

  ZINC ALLOY

• Termination Type:

  SOLDER

• Total Number of Contacts:

  1
