BTS61101SJAXUMA2 - Infineon

Description: IC PWR SWITCH N-CHAN 1:1 DSO-8

Download BTS61101SJAXUMA2 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
BTS61101SJAXUMA2 - Infineon PCB footprint - Small Outline Packages - Small Outline Packages - DSO-8_2021
click to zoom
3D Models
BTS61101SJAXUMA2 - Infineon  - 3D model - Small Outline Packages - DSO-8_2021
click to zoom

BTS61101SJAXUMA2 Details

  • Manufacturer Part Number:

    BTS61101SJAXUMA2

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    DSO-8

  • Country Of Origin:

    Austria, Malaysia

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Factory Lead Time:

    20 Weeks

  • Manufacturer:

    Infineon Technologies AG

  • YTEOL:

    8

  • Additional Feature:

    CURRENT LIMIT:36A; THERMAL SHUTDOWN:200C

  • Adjustable Threshold:

    NO

  • Analog IC - Other Type:

    LOAD SWITCH

  • JESD-30 Code:

    R-PDSO-G8

  • Length:

    5 mm

  • Moisture Sensitivity Level:

    3

  • Number of Channels:

    1

  • Number of Functions:

    1

  • Number of Terminals:

    8

  • Operating Temperature-Max:

    150 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    SOP

  • Package Equivalence Code:

    SOP8,.25

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE

  • Screening Level:

    AEC-Q100

  • Seated Height-Max:

    1.75 mm

  • Supply Voltage-Max (Vsup):

    16 V

  • Supply Voltage-Min (Vsup):

    9 V

  • Supply Voltage-Nom (Vsup):

    13.5 V

  • Surface Mount:

    YES

  • Terminal Finish:

    Tin (Sn)

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    1.27 mm

  • Terminal Position:

    DUAL

  • Width:

    4 mm

BTS61101SJAXUMA2 Frequently Asked Questions (FAQs)

  • The maximum operating temperature range for the BTS61101SJAXUMA2 is -40°C to 150°C.
  • To ensure EMC, follow the layout and grounding guidelines provided in the datasheet, and use proper shielding and filtering techniques to minimize electromagnetic interference.
  • The recommended PCB layout for the BTS61101SJAXUMA2 involves using a multi-layer board with a solid ground plane, and placing the device near the power source to minimize voltage drops.
  • To troubleshoot issues with the BTS61101SJAXUMA2, check the power supply voltage, ensure proper grounding, and verify that the device is operated within the recommended temperature range. Also, check for any signs of physical damage or overheating.
  • Yes, the BTS61101SJAXUMA2 is suitable for high-reliability applications, such as automotive and industrial systems, due to its robust design and high-quality manufacturing process.
