BTT60101EKAXUMA1 - Infineon

Description: INFINEON - BTT60101EKAXUMA1 - POWER LOAD SW, AEC-Q100, 28V, SOIC-14

Download BTT60101EKAXUMA1 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
BTT60101EKAXUMA1 - Infineon PCB footprint - Small Outline Packages - Small Outline Packages - PG-DSO-14-47 EP_1
click to zoom
3D Models
BTT60101EKAXUMA1 - Infineon  - 3D model - Small Outline Packages - PG-DSO-14-47 EP_1
click to zoom

BTT60101EKAXUMA1 Details

  • Manufacturer Part Number:

    BTT60101EKAXUMA1

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Obsolete

  • Package Description:

    SOP-14

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Factory Lead Time:

    4 Weeks

  • Manufacturer:

    Infineon Technologies AG

  • YTEOL:

    0

  • Additional Feature:

    CURRENT LIMIT:140A; THERMAL SHUTDOWN:200C

  • Adjustable Threshold:

    NO

  • Analog IC - Other Type:

    LOAD SWITCH

  • JESD-30 Code:

    R-PDSO-G14

  • Length:

    8.65 mm

  • Moisture Sensitivity Level:

    3

  • Number of Channels:

    1

  • Number of Functions:

    1

  • Number of Terminals:

    14

  • Operating Temperature-Max:

    150 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    HLSOP

  • Package Equivalence Code:

    SOP14,.25

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE, HEAT SINK/SLUG, LOW PROFILE

  • Packing Method:

    TR

  • Screening Level:

    AEC-Q100

  • Seated Height-Max:

    1.7 mm

  • Supply Current-Max (Isup):

    9 mA

  • Supply Voltage-Max (Vsup):

    36 V

  • Supply Voltage-Min (Vsup):

    8 V

  • Supply Voltage-Nom (Vsup):

    28 V

  • Surface Mount:

    YES

  • Terminal Finish:

    Tin (Sn)

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    1.27 mm

  • Terminal Position:

    DUAL

  • Threshold Voltage-Nom:

    +3.5V

  • Width:

    3.9 mm

BTT60101EKAXUMA1 Frequently Asked Questions (FAQs)

  • A 2-layer or 4-layer PCB with a solid ground plane and thermal vias is recommended. The device should be placed near a heat sink or a thermal pad to ensure good heat dissipation.
  • Use a shielded enclosure, keep the device away from high-frequency sources, and use a common-mode choke or ferrite bead to filter out electromagnetic interference (EMI).
  • The maximum allowed voltage on the input pins is 35V, but it's recommended to keep it below 30V to ensure reliable operation and prevent damage to the device.
  • The device is rated for operation up to 150°C, but the maximum junction temperature (Tj) should not exceed 175°C. Ensure proper cooling and thermal management to prevent overheating.
  • Check the input voltage, ensure proper connections, and verify that the enable pin is properly configured. Use a oscilloscope to check the output waveform and verify that it matches the expected behavior.
