BU-61580S3-400W - Data Device Corporation

BU-61580S3-400W Details

• Manufacturer Part Number:

  BU-61580S3-400W

• Pbfree Code:

  No

• Part Life Cycle Code:

  Active

• Part Package Code:

  QIP

• Package Description:

  48.30 X 25.40 MM, 4.19 MM HEIGHT, DIP-70

• Pin Count:

  70

• Country Of Origin:

  Taiwan, USA

• HTS Code:

  8542.31.00.30

• Manufacturer:

  Data Device Corporation

• YTEOL:

  6

• Address Bus Width:

  16

• Boundary Scan:

  NO

• Clock Frequency-Max:

  16 MHz

• Communication Protocol:

  MIL STD 1553A; MIL STD 1553B

• Data Encoding/Decoding Method:

  BIPH-LEVEL(MANCHESTER)

• Data Transfer Rate-Max:

  0.125 MBps

• External Data Bus Width:

  16

• JESD-30 Code:

  R-CQIP-P70

• JESD-609 Code:

  e0

• Length:

  48.26 mm

• Low Power Mode:

  NO

• Number of Serial I/Os:

  2

• Number of Terminals:

  70

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  CERAMIC, METAL-SEALED COFIRED

• Package Code:

  QIP

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  4.19 mm

• Supply Voltage-Max:

  5.5 V

• Supply Voltage-Min:

  4.5 V

• Supply Voltage-Nom:

  5 V

• Surface Mount:

  NO

• Technology:

  CMOS

• Temperature Grade:

  MILITARY

• Terminal Finish:

  Tin/Lead (Sn/Pb)

• Terminal Form:

  PIN/PEG

• Terminal Pitch:

  2.54 mm

• Terminal Position:

  QUAD

• Width:

  25.4 mm

• uPs/uCs/Peripheral ICs Type:

  SERIAL IO/COMMUNICATION CONTROLLER, MIL-STD-1553
