BU-67753LC-102 - Data Device Corporation

BU-67753LC-102 Details

• Manufacturer Part Number:

  BU-67753LC-102

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Taiwan, USA

• HTS Code:

  8542.31.00.30

• Manufacturer:

  Data Device Corporation

• YTEOL:

  7

• Additional Feature:

  LG-MAX; WD-MAX

• Boundary Scan:

  NO

• Bus Compatibility:

  SPI

• Clock Frequency-Max:

  16 MHz

• Communication Protocol:

  MIL STD 1553A; MIL STD 1553B; MIL STD 1760; MCAIR; STANAG 3838

• Data Encoding/Decoding Method:

  BIPH-LEVEL (MANCHESTER)

• Data Transfer Rate-Max:

  0.125 MBps

• JESD-30 Code:

  S-XQCC-N48

• JESD-609 Code:

  e4

• Length:

  7.1 mm

• Low Power Mode:

  NO

• Moisture Sensitivity Level:

  2

• Number of Serial I/Os:

  4

• Number of Terminals:

  48

• On Chip Data RAM Width:

  17

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  UNSPECIFIED

• Package Code:

  HVQCCN

• Package Equivalence Code:

  LCC48,.27SQ,20

• Package Shape:

  SQUARE

• Package Style:

  CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE

• Peak Reflow Temperature (Cel):

  260

• RAM (words):

  4096

• Seated Height-Max:

  1 mm

• Supply Voltage-Max:

  3.46 V

• Supply Voltage-Min:

  3.14 V

• Supply Voltage-Nom:

  3.3 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  MILITARY

• Terminal Finish:

  Nickel/Palladium/Gold (Ni/Pd/Au)

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  QUAD

• Time@Peak Reflow Temperature-Max (s):

  30

• Width:

  7.1 mm

• uPs/uCs/Peripheral ICs Type:

  SERIAL IO/COMMUNICATION CONTROLLER, MIL-STD-1553
