BU2505FV-E2 - ROHM Semiconductor

BU2505FV-E2 Details

• Manufacturer Part Number:

  BU2505FV-E2

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  SSOP

• Pin Count:

  20

• Country Of Origin:

  Philippines

• HTS Code:

  8542.39.00.40

• Factory Lead Time:

  17 Weeks

• Manufacturer:

  ROHM Semiconductor

• YTEOL:

  0

• Analog Output Voltage-Max:

  4.9 V

• Analog Output Voltage-Min:

  0.1 V

• Converter Type:

  D/A CONVERTER

• Input Bit Code:

  BINARY

• Input Format:

  SERIAL

• JESD-30 Code:

  R-PDSO-G20

• Length:

  6.5 mm

• Linearity Error-Max (EL):

  0.3418%

• Number of Bits:

  10

• Number of Functions:

  1

• Number of Terminals:

  20

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -30 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  LSSOP

• Package Equivalence Code:

  TSSOP20,.25

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE, LOW PROFILE, SHRINK PITCH

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  1.45 mm

• Settling Time-Nom (tstl):

  7 µs

• Supply Current-Max:

  2.8 mA

• Supply Voltage-Nom:

  5 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  OTHER

• Terminal Form:

  GULL WING

• Terminal Pitch:

  0.65 mm

• Terminal Position:

  DUAL

• Width:

  4.4 mm
