BU2872AK - ROHM Semiconductor

BU2872AK Details

• Manufacturer Part Number:

  BU2872AK

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  QFP

• Package Description:

  QFP-44

• Pin Count:

  44

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  ROHM Semiconductor

• YTEOL:

  4.5

• Data Input Mode:

  SERIAL

• Display Mode:

  DOT MATRIX

• Input Characteristics:

  SCHMITT TRIGGER

• Interface IC Type:

  VACUUM FLUORESCENT DISPLAY DRIVER

• JESD-30 Code:

  S-PQFP-G44

• JESD-609 Code:

  e3/e2

• Length:

  10 mm

• Multiplexed Display Capability:

  NO

• Number of Functions:

  1

• Number of Segments:

  22

• Number of Terminals:

  44

• Operating Temperature-Max:

  75 °C

• Operating Temperature-Min:

  -25 °C

• Output Characteristics:

  OPEN-DRAIN

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  QFP

• Package Equivalence Code:

  QFP44,.5SQ,32

• Package Shape:

  SQUARE

• Package Style:

  FLATPACK

• Peak Reflow Temperature (Cel):

  260

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  2.25 mm

• Supply Current-Max:

  5 mA

• Supply Voltage-Max:

  5.5 V

• Supply Voltage-Min:

  4.5 V

• Supply Voltage-Nom:

  5 V

• Surface Mount:

  YES

• Temperature Grade:

  COMMERCIAL EXTENDED

• Terminal Finish:

  TIN/TIN COPPER

• Terminal Form:

  GULL WING

• Terminal Pitch:

  0.8 mm

• Terminal Position:

  QUAD

• Time@Peak Reflow Temperature-Max (s):

  10

• Width:

  10 mm

• fmax-Min:

  2 MHz
