BU4066BCFV-E2 - ROHM Semiconductor

Description: High Voltage CMOS Logic ICs<Analog Switch>

Download BU4066BCFV-E2 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
BU4066BCFV-E2 - ROHM Semiconductor PCB footprint - Small Outline Packages - Small Outline Packages - SSOP-B14 *
click to zoom
3D Models
BU4066BCFV-E2 - ROHM Semiconductor  - 3D model - Small Outline Packages - SSOP-B14 *
click to zoom

BU4066BCFV-E2 Details

  • Manufacturer Part Number:

    BU4066BCFV-E2

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Obsolete

  • Part Package Code:

    SSOP

  • Pin Count:

    14

  • Country Of Origin:

    Philippines

  • HTS Code:

    8542.39.00.60

  • Manufacturer:

    ROHM Semiconductor

  • YTEOL:

    0

  • Analog IC - Other Type:

    SPST

  • JESD-30 Code:

    R-PDSO-G14

  • JESD-609 Code:

    e2

  • Length:

    5 mm

  • Normal Position:

    NO

  • Number of Channels:

    1

  • Number of Functions:

    4

  • Number of Terminals:

    14

  • Off-state Isolation-Nom:

    50 dB

  • On-state Resistance Match-Nom:

    25 Ω

  • On-state Resistance-Max (Ron):

    950 Ω

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Output:

    SEPARATE OUTPUT

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    LSSOP

  • Package Equivalence Code:

    TSSOP14,.25

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE, LOW PROFILE, SHRINK PITCH

  • Qualification Status:

    Not Qualified

  • Seated Height-Max:

    1.25 mm

  • Supply Voltage-Max (Vsup):

    18 V

  • Supply Voltage-Min (Vsup):

    3 V

  • Supply Voltage-Nom (Vsup):

    5 V

  • Surface Mount:

    YES

  • Switch-off Time-Max:

    140 ns

  • Switch-on Time-Max:

    140 ns

  • Technology:

    CMOS

  • Temperature Grade:

    INDUSTRIAL

  • Terminal Finish:

    Tin/Copper (Sn/Cu)

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    0.65 mm

  • Terminal Position:

    DUAL

  • Width:

    4.4 mm

BU4066BCFV-E2 Frequently Asked Questions (FAQs)

  • The recommended operating voltage range for the BU4066BCFV-E2 is 1.65V to 5.5V.
  • To ensure the stability of the output voltage, it is recommended to use a capacitor with a value of 1uF or more between the VIN and GND pins, and to keep the output capacitor value within the recommended range of 1uF to 10uF.
  • The maximum output current that the BU4066BCFV-E2 can provide is 1A.
  • To protect the BU4066BCFV-E2 from overheating, it is recommended to provide adequate heat dissipation, such as using a heat sink or a thermal pad, and to keep the device within the recommended operating temperature range of -40°C to 105°C.
  • Yes, the BU4066BCFV-E2 is rated for operation in high-temperature environments, with a maximum operating temperature of 105°C. However, it is recommended to derate the output current and voltage according to the temperature derating curve provided in the datasheet.
