BY269TR - Vishay

BY269TR Details

• Manufacturer Part Number:

  BY269TR

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  E-LALF-W2

• Reach Compliance Code:

  Unknown

• Manufacturer:

  Vishay Intertechnologies

• Case Connection:

  ISOLATED

• Configuration:

  SINGLE

• Diode Element Material:

  SILICON

• Diode Type:

  RECTIFIER DIODE

• JESD-30 Code:

  E-LALF-W2

• JESD-609 Code:

  e2

• Moisture Sensitivity Level:

  1

• Number of Elements:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  175 °C

• Operating Temperature-Min:

  -55 °C

• Output Current-Max:

  0.8 A

• Package Body Material:

  GLASS

• Package Shape:

  ELLIPTICAL

• Package Style:

  LONG FORM

• Peak Reflow Temperature (Cel):

  260

• Rep Pk Reverse Voltage-Max:

  1600 V

• Reverse Recovery Time-Max:

  0.4 µs

• Surface Mount:

  NO

• Technology:

  AVALANCHE

• Terminal Finish:

  TIN SILVER

• Terminal Form:

  WIRE

• Terminal Position:

  AXIAL

• Time@Peak Reflow Temperature-Max (s):

  30
