BZX84B4V3-TP - MCC

BZX84B4V3-TP Details

• Manufacturer Part Number:

  BZX84B4V3-TP

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  PACKAGE-3

• Pin Count:

  3

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.50

• Manufacturer:

  Micro Commercial Components

• YTEOL:

  6.7

• Configuration:

  SINGLE

• Diode Element Material:

  SILICON

• Diode Type:

  ZENER DIODE

• Dynamic Impedance-Max:

  90 Ω

• Forward Voltage-Max (VF):

  0.9 V

• JESD-30 Code:

  R-PDSO-G3

• JESD-609 Code:

  e3

• Knee Impedance-Max:

  600 Ω

• Moisture Sensitivity Level:

  1

• Number of Elements:

  1

• Number of Terminals:

  3

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Packing Method:

  TR

• Peak Reflow Temperature (Cel):

  260

• Polarity:

  UNIDIRECTIONAL

• Power Dissipation-Max:

  0.35 W

• Qualification Status:

  Not Qualified

• Reference Voltage-Nom:

  4.3 V

• Reverse Current-Max:

  3 µA

• Reverse Test Voltage:

  1 V

• Surface Mount:

  YES

• Technology:

  ZENER

• Terminal Finish:

  Matte Tin (Sn)

• Terminal Form:

  GULL WING

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  10

• Voltage Tol-Max:

  2%

• Working Test Current:

  5 mA
