C3M0045065L-TR - Wolfspeed

C3M0045065L-TR Details

• Manufacturer Part Number:

  C3M0045065L-TR

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• Manufacturer:

  Wolfspeed

• YTEOL:

  7

• Case Connection:

  DRAIN

• Configuration:

  SINGLE WITH BUILT-IN DIODE AND KELVIN SENSOR

• DS Breakdown Voltage-Min:

  650 V

• Drain Current-Max (ID):

  49 A

• Drain-source On Resistance-Max:

  0.06 Ω

• FET Technology:

  METAL-OXIDE SEMICONDUCTOR

• Feedback Cap-Max (Crss):

  8 pF

• JESD-30 Code:

  R-PSSO-F8

• JESD-609 Code:

  e3

• Number of Elements:

  1

• Number of Terminals:

  8

• Operating Mode:

  ENHANCEMENT MODE

• Operating Temperature-Max:

  175 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Peak Reflow Temperature (Cel):

  260

• Polarity/Channel Type:

  N-CHANNEL

• Power Dissipation-Max (Abs):

  164 W

• Pulsed Drain Current-Max (IDM):

  132 A

• Reference Standard:

  IEC-60747-8-4

• Surface Mount:

  YES

• Terminal Finish:

  Matte Tin (Sn)

• Terminal Form:

  FLAT

• Terminal Position:

  SINGLE

• Time@Peak Reflow Temperature-Max (s):

  30

• Transistor Application:

  SWITCHING

• Transistor Element Material:

  SILICON
