Part Image

C4GAMUC3680AA0J - Yageo Group

Description: C4G, Film, Metallized Polypropylene, Power, 0.68 uF, 5%, 450 VAC, 850 VDC, 85°C, -40°C, 70°C, 0.05 % , 210 V/us, 11.85 g, 20.5mm, 33mm, 40mm, 1mm, 100

Download C4GAMUC3680AA0J Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
C4GAMUC3680AA0J - Yageo Group PCB footprint - Capacitors, Polarized Axial Diameter Horizontal Mounting - Capacitors, Polarized Axial Diameter Horizontal Mounting - 33mmx20.5mm
click to zoom
3D Models
C4GAMUC3680AA0J - Yageo Group  - 3D model - Capacitors, Polarized Axial Diameter Horizontal Mounting - 33mmx20.5mm
click to zoom

C4GAMUC3680AA0J Details

  • Manufacturer Part Number:

    C4GAMUC3680AA0J

  • Manufacturer:

    YAGEO Corporation

Trust Checks

This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

C4GAMUC3680AA0J Overview

Use the download button to access the C4GAMUC3680AA0J schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like C4GAM, or try a keyword search, such as Film Capacitors
