CAB006M12GM3 Frequently Asked Questions (FAQs)

• What is the recommended PCB layout for optimal thermal performance?
  Wolfspeed recommends a PCB layout with a thermal pad size of at least 10mm x 10mm, with multiple vias to the thermal plane to ensure good heat dissipation. A thermal interface material (TIM) with a thermal conductivity of at least 1 W/m-K is also recommended.
• How do I ensure reliable wire bonding to the device?
  To ensure reliable wire bonding, Wolfspeed recommends using a wire bond process with a minimum bond force of 10 gf and a maximum bond temperature of 150°C. The wire bond pad should be cleaned prior to bonding to remove any contaminants or oxidation.
• What is the maximum allowed voltage stress on the device during assembly and handling?
  Wolfspeed recommends limiting the voltage stress on the device to less than 100V during assembly and handling to prevent damage to the device. Electrostatic discharge (ESD) protection measures should also be taken to prevent damage from static electricity.
• How do I prevent moisture-related failures in the device?
  To prevent moisture-related failures, Wolfspeed recommends storing the devices in a dry environment with a relative humidity of less than 60%. The devices should also be baked at 125°C for 24 hours prior to assembly to remove any moisture that may have accumulated during storage.
• What is the recommended reflow profile for soldering the device?
  Wolfspeed recommends a reflow profile with a peak temperature of 260°C, a dwell time above 220°C of 30-60 seconds, and a ramp rate of 3°C/second. The device should be soldered using a Pb-free solder alloy with a melting point of at least 217°C.
