The recommended land pattern for the CBF25JB22R0 can be found in the Stackpole Electronics Inc. application note AN-040, which provides detailed guidelines for PCB layout and assembly.
The CBF25JB22R0 has a thermal resistance of 35°C/W. To ensure proper thermal management, it is recommended to use a heat sink or thermal pad, and to follow the guidelines outlined in the datasheet for thermal derating.
The CBF25JB22R0 has an operating temperature range of -55°C to 150°C. However, it is recommended to derate the component according to the guidelines in the datasheet to ensure reliable operation.
The CBF25JB22R0 is designed to meet the requirements of MIL-STD-202, Method 204, for vibration testing. However, it is recommended to consult with Stackpole Electronics Inc. or a qualified engineer to determine the suitability of the component for a specific high-vibration application.
The CBF25JB22R0 should be stored in a dry, cool place, away from direct sunlight and moisture. It is recommended to follow the guidelines outlined in the datasheet and in the IPC/JEDEC J-STD-033 standard for handling and storage of moisture-sensitive devices.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
CBF25JB22R0 Overview
Use the download button to access the CBF25JB22R0 schematic symbol and PCB footprint.
To find more CAD model downloads similar to this part, try a partial part number search, like CBF25,
or try a keyword search, such as Wire Wound Resistors
