Texas Instruments provides a recommended PCB layout guide for the CC2652R1FRGZR in the 'CC2652R1FRGZR PCB Layout Guidelines' document, which can be found on the TI website. It's essential to follow these guidelines to ensure optimal performance and minimize electromagnetic interference (EMI).
To optimize power consumption, use the CC2652R1FRGZR's low-power modes, such as the 'Shutdown' or 'Hibernate' modes, when the device is not transmitting or receiving data. Additionally, adjust the radio's transmission power, data rate, and packet size to minimize energy consumption. TI provides a 'Power Management' guide that outlines best practices for power optimization.
The maximum transmission distance of the CC2652R1FRGZR depends on various factors, including the environment, antenna design, and transmission power. In ideal conditions, the CC2652R1FRGZR can achieve a transmission distance of up to 1 km (0.62 miles) at 2.4 GHz. However, this distance can be affected by obstacles, interference, and other environmental factors.
To implement secure communication with the CC2652R1FRGZR, use encryption protocols such as AES-128 or AES-256, and authentication mechanisms like SHA-256. TI provides a 'Security' guide that outlines best practices for secure communication with the CC2652R1FRGZR. Additionally, consider using secure protocols like TLS or DTLS for end-to-end encryption.
The CC2652R1FRGZR supports a maximum data rate of 2 Mbps in Bluetooth 5.0 mode and up to 4 Mbps in proprietary mode. However, the actual data rate may vary depending on the specific application, environment, and transmission conditions.
