The maximum frequency of operation for the CD4011UBMT is typically around 10 MHz, but it can vary depending on the specific application and operating conditions.
To ensure proper operation, the CD4011UBMT requires a single power supply voltage (VDD) between 3V and 18V, with a recommended operating voltage of 5V. Additionally, a decoupling capacitor of 0.1uF to 1uF should be placed close to the VDD pin to filter out noise and ensure stable operation.
The input voltage threshold for the CD4011UBMT is typically around 1.5V to 2.5V, depending on the supply voltage. This means that an input voltage above this threshold will be considered a logic high, while an input voltage below this threshold will be considered a logic low.
Yes, the CD4011UBMT can be used with a 3.3V power supply. However, the output voltage levels may not be as high as those obtained with a 5V power supply, and the noise immunity may be reduced. Additionally, the maximum frequency of operation may be lower at 3.3V compared to 5V.
Unused inputs on the CD4011UBMT should be tied to a valid logic level (either VDD or GND) to prevent them from floating and causing unwanted oscillations or noise. This is especially important for CMOS devices like the CD4011UBMT, which are sensitive to input noise and can oscillate if left unconnected.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
CD4011UBMT Overview
Use the download button to access the CD4011UBMT schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like CD401,
or try a keyword search, such as Gates
About Texas Instruments
Texas Instruments (TI) designs and manufactures semiconductors and integrated circuits for a wide range of applications. The company's product portfolio includes analog chips, which are essential for managing power and signal functions in electronic devices, and embedded processors, which serve as the brains in various systems, enabling functionality in everything from industrial equipment to consumer electronics. TI's innovations in semiconductor technology have made it a leader in the industry.
