The maximum operating frequency of the CD4069UB is typically around 10 MHz, but it can vary depending on the specific application and operating conditions.
Yes, the CD4069UB can be used as a level shifter, but it's not the most efficient or recommended solution. It's primarily designed as a hex inverter, and using it as a level shifter may require additional circuitry and may not provide the best performance.
The input impedance of the CD4069UB is typically around 1 kΩ to 10 kΩ, but it can vary depending on the specific application and operating conditions.
Yes, the CD4069UB can operate with a 3.3V supply voltage, but it's recommended to check the datasheet for specific voltage and current requirements to ensure proper operation.
The propagation delay of the CD4069UB is typically around 10-20 ns, but it can vary depending on the specific application and operating conditions.
