CDS6004828 Frequently Asked Questions (FAQs)

• What is the recommended PCB layout for optimal thermal performance?
  Cosel recommends a PCB layout with a large copper area connected to the module's thermal pad to ensure efficient heat dissipation. A minimum of 2 oz copper thickness is recommended, and the copper area should be connected to a solid ground plane to reduce thermal resistance.
• How do I ensure reliable start-up and operation with a high-capacitance output filter?
  To ensure reliable start-up and operation with a high-capacitance output filter, Cosel recommends adding a soft-start circuit or a ramp-up circuit to limit the inrush current during start-up. Additionally, the output voltage should be monitored and the module should be enabled only when the output voltage is within the specified range.
• What is the maximum allowed output capacitance for this module?
  The maximum allowed output capacitance for the CDS6004828 is 2200uF. Exceeding this value may cause instability or oscillation in the output voltage. It is recommended to consult with Cosel's application engineers for specific guidance on output capacitance selection.
• Can I use this module in a high-altitude application?
  The CDS6004828 is designed to operate up to 5,000 meters (16,400 feet) above sea level. However, derating of the output power may be necessary for high-altitude applications. Cosel recommends consulting with their application engineers for specific guidance on high-altitude operation.
• What is the recommended input fuse rating for this module?
  Cosel recommends using a fuse with a rating of 5A to 10A, depending on the input voltage and the system's fault current requirements. The fuse should be able to handle the maximum input current of the module during fault conditions.
