CHS4004812-L5 - Cosel

CHS4004812-L5 Details

• Manufacturer Part Number:

  CHS4004812-L5

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  ,

• Reach Compliance Code:

  Unknown

• ECCN Code:

  EAR99

• Manufacturer:

  Cosel USA Inc

• YTEOL:

  7

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  CE, CSA, CUL, C-UL-US, EN, TUV, UL

• Efficiency (Main Output):

  95%

• Input Voltage-Max:

  76 V

• Input Voltage-Min:

  36 V

• Input Voltage-Nom:

  48 V

• JESD-30 Code:

  R-XDIP-P5

• Length:

  58.4 mm

• Line Regulation-Max:

  0.2%

• Load Regulation-Max:

  0.2%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  5

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  33 A

• Output Voltage-Max:

  13.2 V

• Output Voltage-Min:

  10.8 V

• Output Voltage-Nom:

  12 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  DIP

• Package Equivalence Code:

  DIP5,2,600/500

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Peak Reflow Temperature (Cel):

  260

• Protections:

  OVER CURRENT; OVER VOLTAGE

• Ripple Voltage (Main Out):

  0.0707 Vrms

• Seated Height-Max:

  9.5 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Form:

  PIN/PEG

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  15

• Total Power Output-Max:

  396 W

• Trim/Adjustable Output:

  YES

• Warm-up Time:

  0.05 s

• Width:

  36.8 mm
