CMD275P4 - Qorvo

Description: DC-26.5 GHz (L, S, X, Ku, K Band) Low Phase Noise Amplifier

Download CMD275P4 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
CMD275P4 - Qorvo PCB footprint - Quad Flat No-Lead - Quad Flat No-Lead - 24-Lead QFN
click to zoom
3D Models
CMD275P4 - Qorvo  - 3D model - Quad Flat No-Lead - 24-Lead QFN
click to zoom

CMD275P4 Details

  • Manufacturer Part Number:

    CMD275P4

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    QFN-24

  • ECCN Code:

    EAR99

  • Factory Lead Time:

    22 Weeks

  • Manufacturer:

    Qorvo

  • YTEOL:

    7

  • Characteristic Impedance:

    50 Ω

  • Construction:

    COMPONENT

  • Gain:

    13 dB

  • Input Power-Max (CW):

    10 dBm

  • JESD-609 Code:

    e3

  • Mounting Feature:

    SURFACE MOUNT

  • Number of Functions:

    1

  • Number of Terminals:

    24

  • Operating Frequency-Max:

    26500 MHz

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Equivalence Code:

    LCC24,.16SQ,20

  • Power Supplies:

    5 V

  • RF/Microwave Device Type:

    WIDE BAND LOW POWER

  • Supply Current-Max:

    110 mA

  • Surface Mount:

    YES

  • Technology:

    GAAS

  • Terminal Finish:

    MATTE TIN

CMD275P4 Frequently Asked Questions (FAQs)

  • A 4-layer PCB with a solid ground plane and a separate power plane is recommended. The device should be placed near the edge of the board to minimize the distance to the antenna. A 50-ohm microstrip line should be used to connect the device to the antenna.
  • The optimal bias point for maximum power efficiency is typically around 3.5V to 4.5V. The bias current should be set to around 200-300 mA for optimal performance. The device should be operated in a Class-AB mode to achieve the best trade-off between power efficiency and linearity.
  • A simple L-match or pi-match network can be used to match the device to a 50-ohm load. The values of the matching components will depend on the specific application and frequency of operation. A network analyzer can be used to optimize the matching network for maximum power transfer.
  • The device should be mounted on a heat sink or thermal pad to dissipate heat. The heat sink should be designed to provide good thermal conductivity and should be attached to the device using a thermal interface material. The device should be operated at a temperature below 85°C to ensure reliable operation.
  • The maximum input power that the CMD275P4 can handle is around 10 dBm. Exceeding this power level can cause damage to the device. Input power should be limited using an attenuator or limiter to prevent damage.
