CMF03(TE12L,Q) - Toshiba

CMF03(TE12L,Q) Details

• Manufacturer Part Number:

  CMF03(TE12L,Q)

• Part Life Cycle Code:

  Obsolete

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.70

• Manufacturer:

  Toshiba America Electronic Components

• YTEOL:

  0

• Application:

  FAST RECOVERY

• Configuration:

  SINGLE

• Diode Element Material:

  SILICON

• Diode Type:

  RECTIFIER DIODE

• Forward Voltage-Max (VF):

  2.5 V

• JESD-30 Code:

  R-PDSO-F2

• Non-rep Pk Forward Current-Max:

  10 A

• Number of Elements:

  1

• Number of Phases:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  0.5 A

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Rep Pk Reverse Voltage-Max:

  900 V

• Reverse Current-Max:

  50 µA

• Reverse Recovery Time-Max:

  0.1 µs

• Reverse Test Voltage:

  900 V

• Surface Mount:

  YES

• Terminal Form:

  FLAT

• Terminal Position:

  DUAL
