CMLT7820G - Central Semiconductor

CMLT7820G Details

• Manufacturer Part Number:

  CMLT7820G

• Pbfree Code:

  No

• Part Life Cycle Code:

  Transferred

• Package Description:

  HALOGEN FREE, PICOMINI-6

• Pin Count:

  6

• ECCN Code:

  EAR99

• Manufacturer:

  Central Semiconductor Corp

• YTEOL:

  7

• Collector Current-Max (IC):

  1 A

• Collector-Emitter Voltage-Max:

  60 V

• Configuration:

  SINGLE

• DC Current Gain-Min (hFE):

  100

• JESD-30 Code:

  R-PDSO-F6

• JESD-609 Code:

  e0

• Number of Elements:

  1

• Number of Terminals:

  6

• Operating Temperature-Max:

  150 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Polarity/Channel Type:

  PNP

• Qualification Status:

  Not Qualified

• Surface Mount:

  YES

• Terminal Finish:

  Tin/Lead (Sn/Pb)

• Terminal Form:

  FLAT

• Terminal Position:

  DUAL

• Transistor Application:

  SWITCHING

• Transistor Element Material:

  SILICON

• Transition Frequency-Nom (fT):

  150 MHz
