CONBNC002 - TE Connectivity

CONBNC002 Details

• Manufacturer Part Number:

  CONBNC002

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.10

• Factory Lead Time:

  5 Days

• Manufacturer:

  TE Connectivity

• Body Breadth:

  0.52 inch

• Body Depth:

  0.55 inch

• Body Diameter:

  0.5 inch

• Body Length:

  0.58 inch

• Body/Shell Style:

  JACK

• Characteristic Impedance:

  50 Ω

• Connector Type:

  RF BNC CONNECTOR

• Contact Gender:

  FEMALE

• Contact Style:

  COAX

• Coupling Type:

  BAYONET

• Durability:

  500 Cycles

• Filter Feature:

  NO

• Insertion Loss:

  0.89 dB

• Insulator Material:

  POLYPROPYLENE

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD AND PANEL

• Number of Ports:

  1

• Operating Frequency-Max:

  1 GHz

• Operating Temperature-Max:

  165 °C

• Operating Temperature-Min:

  -60 °C

• Option:

  GENERAL PURPOSE

• Panel Mount:

  YES

• Shell Finish:

  NICKEL

• Shell Material:

  ZINC ALLOY

• Terminal Length:

  0.14 inch

• Termination Type:

  SOLDER

• Total Number of Contacts:

  1

• VSWR:

  1.9
