CPV364M4U - Vishay

CPV364M4U Details

• Manufacturer Part Number:

  CPV364M4U

• Pbfree Code:

  No

• Part Life Cycle Code:

  Active Unconfirmed

• Pin Count:

  13

• ECCN Code:

  EAR99

• Manufacturer:

  Vishay Intertechnologies

• YTEOL:

  2

• Additional Feature:

  ULTRA FAST SOFT

• Case Connection:

  ISOLATED

• Collector Current-Max (IC):

  20 A

• Collector-Emitter Voltage-Max:

  600 V

• Configuration:

  BRIDGE, 6 ELEMENTS WITH BUILT-IN DIODE

• Gate-Emitter Voltage-Max:

  20 V

• JESD-30 Code:

  R-PSFM-T13

• Number of Elements:

  6

• Number of Terminals:

  13

• Operating Temperature-Max:

  150 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Polarity/Channel Type:

  N-CHANNEL

• Power Dissipation-Max (Abs):

  63 W

• Qualification Status:

  Not Qualified

• Surface Mount:

  NO

• Terminal Form:

  THROUGH-HOLE

• Terminal Position:

  SINGLE

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Transistor Application:

  POWER CONTROL

• Transistor Element Material:

  SILICON

• Turn-off Time-Nom (toff):

  220 ns

• Turn-on Time-Nom (ton):

  39 ns

• VCEsat-Max:

  2.1 V
