CSTCR4M00G15L99-R0 Frequently Asked Questions (FAQs)

• What is the recommended land pattern for this component?
  The recommended land pattern for the CSTCR4M00G15L99-R0 is a rectangular pad with a size of 3.2mm x 1.3mm, with a 0.5mm keep-out area around the pad to ensure proper soldering and to prevent electrical shorts.
• How do I handle the component during assembly to prevent damage?
  Handle the component by the edges or the body, avoiding touching the electrodes or the resonator surface to prevent damage from electrostatic discharge or contamination. Use an anti-static wrist strap or mat, and ensure the assembly area is electrostatic-protected.
• What is the maximum allowable vibration for this component?
  The CSTCR4M00G15L99-R0 is designed to withstand vibrations up to 10G (10 times the acceleration due to gravity) in the frequency range of 10-2000 Hz, making it suitable for most industrial and consumer applications.
• Can I use this component in high-temperature applications?
  The CSTCR4M00G15L99-R0 is rated for operation up to 125°C, but it's recommended to derate the frequency and stability specifications above 85°C. Consult the datasheet and application notes for specific guidance on high-temperature operation.
• How do I ensure the component is properly soldered?
  Use a soldering iron with a temperature of 250°C to 270°C, and apply a small amount of solder paste or flux to the pads. Ensure the component is properly aligned and seated on the PCB before soldering, and avoid applying excessive heat or force during the soldering process.
