CY15V102QN-50LHXI - Infineon

CY15V102QN-50LHXI Details

• Manufacturer Part Number:

  CY15V102QN-50LHXI

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Manufacturer:

  Infineon Technologies AG

• YTEOL:

  8

• Additional Feature:

  DATA RETENTION TIME @ 85 DEGREE CENTIGRADE; 2KV ESD AVAILABLE

• Clock Frequency-Max (fCLK):

  50 MHz

• Data Retention Time-Min:

  10

• Endurance:

  1000000000000000 Write/Erase Cycles

• JESD-30 Code:

  R-PDSO-N8

• JESD-609 Code:

  e3

• Length:

  6 mm

• Memory Density:

  2097152 bit

• Memory IC Type:

  FRAM

• Memory Width:

  8

• Moisture Sensitivity Level:

  3

• Number of Functions:

  1

• Number of Terminals:

  8

• Number of Words:

  262144 words

• Number of Words Code:

  256000

• Operating Mode:

  SYNCHRONOUS

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Organization:

  256KX8

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  HVSON

• Package Equivalence Code:

  SOLCC8,.25

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE

• Parallel/Serial:

  SERIAL

• Seated Height-Max:

  0.8 mm

• Serial Bus Type:

  SPI

• Standby Current-Max:

  0.000065 A

• Standby Voltage-Min:

  1.71 V

• Supply Current-Max:

  0.0037 mA

• Supply Voltage-Max (Vsup):

  1.89 V

• Supply Voltage-Min (Vsup):

  1.71 V

• Supply Voltage-Nom (Vsup):

  1.8 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Terminal Finish:

  Pure Tin (Sn)

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  1.27 mm

• Terminal Position:

  DUAL

• Width:

  5 mm

• Write Protection:

  HARDWARE/SOFTWARE
