The recommended crystal oscillator frequency for the CY8C4045LQI-S412T is 32.768 kHz. This frequency is used as the clock source for the internal real-time clock (RTC) and watchdog timer.
The GPIO pins on the CY8C4045LQI-S412T can be configured as analog or digital inputs using the Pin Configuration Register (PCR). The PCR register is used to set the pin mode, drive mode, and input buffer mode for each GPIO pin.
The maximum current that can be sourced or sunk by the GPIO pins on the CY8C4045LQI-S412T is 25 mA. However, the total current sourced or sunk by all GPIO pins should not exceed 150 mA to ensure reliable operation.
The internal voltage regulator on the CY8C4045LQI-S412T can be used to power external components by connecting the VREG pin to the external component's power pin. The VREG pin provides a regulated 3.3V output that can source up to 50 mA of current.
The VBAT pin on the CY8C4045LQI-S412T is used to connect a battery or other power source to the internal real-time clock (RTC) and other low-power modes. The VBAT pin allows the microcontroller to retain its RTC and other settings even when the main power source is removed.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
CY8C4045LQI-S412T Overview
Use the download button to access the CY8C4045LQI-S412T schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like CY8C4,
or try a keyword search, such as Other uPs/uCs/Peripheral ICs
