D4S20D-40MA5-F - Rosenberger

D4S20D-40MA5-F Frequently Asked Questions (FAQs)

• What is the recommended torque value for mating and unmating the connector?
  The recommended torque value is 0.4 Nm to 0.6 Nm (3.5 in-lbs to 5.3 in-lbs) for mating and unmating the connector, as specified in the Rosenberger application notes.
• Is the D4S20D-40MA5-F connector suitable for high-vibration applications?
  Yes, the D4S20D-40MA5-F connector is designed to withstand high-vibration environments, with a vibration resistance of 10 g (sinusoidal) and 20 g (random) according to IEC 61373 Cat. 2.
• Can I use the D4S20D-40MA5-F connector in harsh environments, such as high-temperature or high-humidity applications?
  Yes, the D4S20D-40MA5-F connector is designed to operate in harsh environments, with an operating temperature range of -40°C to +125°C and a humidity range of 5% to 95% RH, non-condensing.
• What is the typical insertion loss and return loss of the D4S20D-40MA5-F connector?
  The typical insertion loss of the D4S20D-40MA5-F connector is ≤ 0.5 dB up to 20 GHz, and the typical return loss is ≥ 20 dB up to 20 GHz, as specified in the Rosenberger datasheet.
• Is the D4S20D-40MA5-F connector compatible with other Rosenberger connectors, such as the D4S20D-40MA5-M?
  Yes, the D4S20D-40MA5-F connector is compatible with other Rosenberger connectors, including the D4S20D-40MA5-M, as they share the same mating interface and electrical characteristics.
