DAC1210LCJ-1 - Texas Instruments

DAC1210LCJ-1 Details

• Manufacturer Part Number:

  DAC1210LCJ-1

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  DIP

• Package Description:

  CARAMIC, DIP-24

• Pin Count:

  24

• HTS Code:

  8542.39.00.40

• Manufacturer:

  Texas Instruments

• YTEOL:

  0

• Converter Type:

  D/A CONVERTER

• Input Bit Code:

  BINARY

• Input Format:

  PARALLEL, WORD

• JESD-30 Code:

  R-GDIP-T24

• Length:

  32.766 mm

• Linearity Error-Max (EL):

  0.05%

• Number of Bits:

  12

• Number of Functions:

  1

• Number of Terminals:

  24

• Operating Temperature-Max:

  70 °C

• Package Body Material:

  CERAMIC, GLASS-SEALED

• Package Code:

  DIP

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Seated Height-Max:

  4.572 mm

• Settling Time-Nom (tstl):

  1 µs

• Supply Voltage-Nom:

  11.4 V

• Surface Mount:

  NO

• Temperature Grade:

  COMMERCIAL

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  2.54 mm

• Terminal Position:

  DUAL

• Width:

  15.24 mm
