The recommended power-up sequence is to apply VCC first, followed by AVCC, and then the digital supply (DVCC). This ensures that the analog and digital sections of the device are powered up correctly.
The DAC71416RHAR has an output voltage range of 0 to VREF. To ensure accurate output voltage, the reference voltage (VREF) should be set to a value that is within the specified range of 2.7V to 5.5V. Additionally, the output voltage should be buffered with an op-amp if it needs to drive a load.
The settling time of the DAC71416RHAR is typically around 10μs, but it can vary depending on the output voltage range, load capacitance, and other factors. It's recommended to consult the datasheet and application notes for more information on settling time and how to optimize it for specific applications.
The DAC71416RHAR has a 16-bit parallel interface that can be easily interfaced with a microcontroller. The microcontroller can write data to the DAC's input registers, and the DAC will convert the digital data to an analog output voltage. The interface can be synchronous or asynchronous, depending on the application requirements.
The power consumption of the DAC71416RHAR depends on the operating mode, output voltage range, and other factors. Typically, the power consumption is around 15mW to 30mW, but it can be as low as 1.5mW in power-down mode. Consult the datasheet for more information on power consumption and how to optimize it for specific applications.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
DAC71416RHAR Overview
Use the download button to access the DAC71416RHAR schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like DAC71,
or try a keyword search, such as Digital to Analog Converters
