DAMM-15P-M-F225 - ITT CANNON

DAMM-15P-M-F225 Details

• Manufacturer Part Number:

  DAMM-15P-M-F225

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.30

• Factory Lead Time:

  20 Weeks

• Manufacturer:

  ITT Interconnect Solutions

• YTEOL:

  8.18

• Connector Type:

  D SUBMINIATURE CONNECTOR

• Contact Finish Mating:

  NOT SPECIFIED

• Contact Gender:

  MALE

• Contact Material:

  NOT SPECIFIED

• Contact Resistance:

  7.5 mΩ

• Dielectric Withstanding Voltage:

  1000VAC V

• Durability:

  500 Cycles

• Empty Shell:

  NO

• Filter Feature:

  NO

• Insulator Color:

  BLACK

• Insulator Material:

  POLYETHYLENE

• Mixed Contacts:

  NO

• Mounting Option 1:

  HOLE .120

• Mounting Style:

  STRAIGHT

• Mounting Type:

  BOARD

• Number Of Connectors:

  ONE

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -55 °C

• Option:

  GENERAL PURPOSE

• Plating Thickness:

  50u inch

• Rated Current (Power):

  7.5 A

• Reference Standard:

  UL

• Shell Material:

  STAINLESS STEEL

• Shell Size:

  2/A

• Termination Type:

  SOLDER

• Total Number of Contacts:

  15

• UL Flammability Code:

  94V-0

• Wire Size-Max:

  20 AWG

• Wire Size-Min:

  28 AWG
