DCM3623TA5N26B4T70 - VICOR

DCM3623TA5N26B4T70 Details

• Manufacturer Part Number:

  DCM3623TA5N26B4T70

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  PACKAGE-9

• ECCN Code:

  EAR99

• Factory Lead Time:

  28 Weeks

• Manufacturer:

  Vicor Corporation

• YTEOL:

  7

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  IEC, EN, UL, CE, UKCA

• Efficiency (Main Output):

  92.6%

• Input Voltage-Max:

  154 V

• Input Voltage-Min:

  43 V

• Input Voltage-Nom:

  100 V

• JESD-30 Code:

  R-XDMA-T9

• JESD-609 Code:

  e4

• Length:

  38.72 mm

• Load Regulation-Max:

  2%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  9

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  10 A

• Output Voltage-Max:

  26.4 V

• Output Voltage-Min:

  14.4 V

• Output Voltage-Nom:

  24 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  DMA

• Package Equivalence Code:

  MODULE,9LEAD,1.5

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Protections:

  OVER CURRENT, OVER TEMPERATURE, OUTPUT OVER VOLTAGE, SHORT CIRCUIT

• Ripple Voltage (Main Out):

  0.2018 Vrms

• Screening Level:

  IEC/EN/UL 62368-1

• Seated Height-Max:

  7.31 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Finish:

  Nickel/Palladium/Gold (Ni/Pd/Au)

• Terminal Form:

  THROUGH-HOLE

• Terminal Position:

  DUAL

• Total Power Output-Max:

  240 W

• Trim/Adjustable Output:

  YES

• Warm-up Time:

  0.2 s

• Width:

  22.8 mm
