DDS39RFS10ACK - Texas Instruments

DDS39RFS10ACK Details

• Manufacturer Part Number:

  DDS39RFS10ACK

• Brand Name:

  Texas Instruments

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  3A001.A.5.B.1

• HTS Code:

  8542.39.00.90

• Manufacturer:

  Texas Instruments

• YTEOL:

  15

• Analog Output Voltage-Max:

  2.39 V

• Analog Output Voltage-Min:

  1.21 V

• Converter Type:

  D/A CONVERTER

• Input Bit Code:

  OFFSET BINARY, 2'S COMPLEMENT BINARY

• Input Format:

  SERIAL

• JESD-30 Code:

  S-PBGA-B90

• Length:

  17 mm

• Linearity Error-Max (EL):

  0.01373291%

• Moisture Sensitivity Level:

  3

• Negative Supply Voltage-Nom:

  -1.8 V

• Number of Bits:

  16

• Number of Functions:

  1

• Number of Terminals:

  90

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  BGA

• Package Equivalence Code:

  BGA90,16X16,40

• Package Shape:

  SQUARE

• Package Style:

  GRID ARRAY

• Peak Reflow Temperature (Cel):

  260

• Sample Rate:

  20480 MHz

• Seated Height-Max:

  2.78 mm

• Supply Voltage-Nom:

  1.8 V

• Surface Mount:

  YES

• Terminal Form:

  BALL

• Terminal Pitch:

  1 mm

• Terminal Position:

  BOTTOM

• Time@Peak Reflow Temperature-Max (s):

  30

• Width:

  17 mm
