DF5A5.6FU - Toshiba

DF5A5.6FU Details

• Manufacturer Part Number:

  DF5A5.6FU

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  SOD

• Package Description:

  1-2V1B, USV, 5 PIN

• Pin Count:

  5

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.50

• Manufacturer:

  Toshiba America Electronic Components

• YTEOL:

  7.1

• Configuration:

  COMMON ANODE, 4 ELEMENTS

• Diode Element Material:

  SILICON

• Diode Type:

  ZENER DIODE

• Dynamic Impedance-Max:

  40 Ω

• JESD-30 Code:

  R-PDSO-G5

• Number of Elements:

  4

• Number of Terminals:

  5

• Operating Temperature-Max:

  125 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Polarity:

  UNIDIRECTIONAL

• Power Dissipation-Max:

  0.2 W

• Qualification Status:

  Not Qualified

• Reference Standard:

  IEC-61000-4-2

• Reference Voltage-Nom:

  5.6 V

• Reverse Current-Max:

  1 µA

• Reverse Test Voltage:

  2.5 V

• Surface Mount:

  YES

• Technology:

  ZENER

• Terminal Form:

  GULL WING

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Voltage Tol-Max:

  6.19%

• Working Test Current:

  5 mA
