DF80R07W1H5FP_B11 - Infineon

DF80R07W1H5FP_B11 Details

• Manufacturer Part Number:

  DF80R07W1H5FP_B11

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Germany, Mainland China

• ECCN Code:

  EAR99

• Manufacturer:

  Infineon Technologies AG

• YTEOL:

  5.35

• Case Connection:

  ISOLATED

• Collector Current-Max (IC):

  20 A

• Collector-Emitter Voltage-Max:

  650 V

• Configuration:

  SEPARATE, 2 ELEMENTS WITH BUILT-IN DIODE AND THERMISTOR

• Gate-Emitter Thr Voltage-Max:

  4.75 V

• Gate-Emitter Voltage-Max:

  20 V

• JESD-30 Code:

  R-XUFM-X18

• Number of Elements:

  2

• Number of Terminals:

  18

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  UNSPECIFIED

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Polarity/Channel Type:

  N-CHANNEL

• Surface Mount:

  NO

• Terminal Form:

  UNSPECIFIED

• Terminal Position:

  UPPER

• Transistor Element Material:

  SILICON

• Turn-off Time-Nom (toff):

  124 ns

• Turn-on Time-Nom (ton):

  17 ns

• VCEsat-Max:

  1.72 V
