DI78L05ZAB - Diotec

DI78L05ZAB Details

• Manufacturer Part Number:

  DI78L05ZAB

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  TO-92, 3-PIN

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Date Of Intro:

  2019-12-10

• Manufacturer:

  Diotec Semiconductor AG

• YTEOL:

  5.6

• Adjustability:

  FIXED

• Dropout Voltage1-Nom:

  1.7 V

• Input Voltage Absolute-Max:

  30 V

• Input Voltage-Max:

  20 V

• Input Voltage-Min:

  7 V

• JESD-30 Code:

  O-PBCY-T3

• JESD-609 Code:

  e3

• Line Regulation-Max:

  0.15%

• Load Regulation-Max(%):

  0.06%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  3

• Operating Temperature TJ-Max:

  125 °C

• Operating Temperature TJ-Min:

  -40 °C

• Output Current1-Max:

  0.1 A

• Output Voltage1-Max:

  5.25 V

• Output Voltage1-Min:

  4.75 V

• Output Voltage1-Nom:

  5 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  TO-92

• Package Equivalence Code:

  SIP3,.1,50

• Package Shape:

  ROUND

• Package Style:

  CYLINDRICAL

• Peak Reflow Temperature (Cel):

  260

• Regulator Type:

  FIXED POSITIVE SINGLE OUTPUT STANDARD REGULATOR

• Surface Mount:

  NO

• Terminal Finish:

  Matte Tin (Sn) - annealed

• Terminal Form:

  THROUGH-HOLE

• Terminal Position:

  BOTTOM

• Time@Peak Reflow Temperature-Max (s):

  10

• Voltage Tolerance-Max:

  5%
