DLP471TEA0FYN - Texas Instruments

DLP471TEA0FYN Details

• Manufacturer Part Number:

  DLP471TEA0FYN

• Brand Name:

  Texas Instruments

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.90

• Date Of Intro:

  2019-12-21

• Manufacturer:

  Texas Instruments

• YTEOL:

  0

• Consumer IC Type:

  CONSUMER CIRCUIT

• JESD-30 Code:

  R-CPGA-P149

• JESD-609 Code:

  e4

• Length:

  32.2 mm

• Number of Functions:

  1

• Number of Terminals:

  149

• Operating Temperature-Max:

  70 °C

• Package Body Material:

  CERAMIC, METAL-SEALED COFIRED

• Package Code:

  SPGA

• Package Equivalence Code:

  PGA149,20x16

• Package Shape:

  RECTANGULAR

• Package Style:

  GRID ARRAY, SHRINK PITCH

• Seated Height-Max:

  3.47 mm

• Surface Mount:

  NO

• Temperature Grade:

  COMMERCIAL

• Terminal Finish:

  Nickel/Palladium/Gold (Ni/Pd/Au)

• Terminal Form:

  PIN/PEG

• Terminal Pitch:

  1.27 mm

• Terminal Position:

  BOTTOM

• Width:

  22.3 mm
