DLP5534AFYKQ1 - Texas Instruments

DLP5534AFYKQ1 Details

• Manufacturer Part Number:

  DLP5534AFYKQ1

• Brand Name:

  Texas Instruments

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.90

• Date Of Intro:

  2019-09-26

• Manufacturer:

  Texas Instruments

• YTEOL:

  15

• Consumer IC Type:

  CONSUMER CIRCUIT

• JESD-30 Code:

  R-CPGA-P149

• JESD-609 Code:

  e4

• Length:

  32.2 mm

• Number of Functions:

  1

• Number of Terminals:

  149

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  CERAMIC, METAL-SEALED COFIRED

• Package Code:

  SPGA

• Package Equivalence Code:

  PGA149,20x16

• Package Shape:

  RECTANGULAR

• Package Style:

  GRID ARRAY, SHRINK PITCH

• Screening Level:

  AEC-Q100

• Supply Voltage-Max (Vsup):

  1.95 V

• Supply Voltage-Min (Vsup):

  1.7 V

• Surface Mount:

  NO

• Temperature Grade:

  INDUSTRIAL

• Terminal Finish:

  Nickel/Palladium/Gold (Ni/Pd/Au)

• Terminal Form:

  PIN/PEG

• Terminal Pitch:

  1.27 mm

• Terminal Position:

  PERPENDICULAR

• Width:

  22.3 mm
