DLPC23STZDQRQ1 - Texas Instruments

DLPC23STZDQRQ1 Details

• Manufacturer Part Number:

  DLPC23STZDQRQ1

• Brand Name:

  Texas Instruments

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  3A001.a.3

• HTS Code:

  8542.31.00.30

• Date Of Intro:

  2020-09-07

• Manufacturer:

  Texas Instruments

• YTEOL:

  15

• Bit Size:

  24

• Bus Compatibility:

  I2C, SPI

• Clock Frequency-Max:

  110 MHz

• JESD-30 Code:

  S-PBGA-B324

• Length:

  23 mm

• Number of Terminals:

  324

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  HBGA

• Package Equivalence Code:

  BGA324,22X22,40

• Package Shape:

  SQUARE

• Package Style:

  GRID ARRAY, HEAT SINK/SLUG

• Screening Level:

  AEC-Q100

• Seated Height-Max:

  2.352 mm

• Supply Current-Max:

  390.7 mA

• Supply Voltage-Max:

  1.155 V

• Supply Voltage-Min:

  1.045 V

• Supply Voltage-Nom:

  1.1 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Terminal Form:

  BALL

• Terminal Pitch:

  1 mm

• Terminal Position:

  BOTTOM

• Width:

  23 mm

• uPs/uCs/Peripheral ICs Type:

  DISPLAY CONTROLLER, DLP
