DLVB-4230 - BETA

DLVB-4230 Details

• Manufacturer Part Number:

  DLVB-4230

• Part Life Cycle Code:

  Transferred

• ECCN Code:

  EAR99

• Manufacturer:

  BETA Transformer Technology Corp

• Additional Feature:

  HEIGHT DIMENSION INCLUDES TERMINALS ALSO; STANDARD: MIL-PRF-21038

• Application:

  GENERAL PURPOSE

• Height:

  4.191 mm

• Isolation Voltage:

  100 V

• JESD-609 Code:

  e0

• Length:

  24.384 mm

• Mounting Feature:

  SURFACE MOUNT

• Number of Functions:

  1

• Operating Temperature-Max:

  130 °C

• Operating Temperature-Min:

  -55 °C

• Packing Method:

  TAPE & REEL

• Pulse Rise Time-Max:

  250 ns

• Surface Mount:

  YES

• Terminal Finish:

  TIN LEAD OVER NICKEL

• Transformer Type:

  PULSE TRANSFORMER

• Turns Ratio (Np:Ns):

  1:2.07

• Width:

  14.605 mm
