DM9000AEP - DAVICOM

DM9000AEP Details

• Manufacturer Part Number:

  DM9000AEP

• Part Life Cycle Code:

  Contact Manufacturer

• Package Description:

  LQFP-48

• HTS Code:

  8542.31.00.30

• Manufacturer:

  Davicom Semiconductor Inc

• Additional Feature:

  IEEE802.3X

• Boundary Scan:

  NO

• Bus Compatibility:

  ISA

• Clock Frequency-Max:

  25 MHz

• Communication Protocol:

  SYNC, BIT, BYTE, ETHERNET

• Data Encoding/Decoding Method:

  NRZ; NRZI; BIPH-LEVEL(MANCHESTER)

• Data Transfer Rate-Max:

  12.5 MBps

• External Data Bus Width:

  16

• JESD-30 Code:

  S-PQFP-G48

• Length:

  7 mm

• Low Power Mode:

  YES

• Number of Serial I/Os:

  2

• Number of Terminals:

  48

• Operating Temperature-Max:

  70 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  LFQFP

• Package Shape:

  SQUARE

• Package Style:

  FLATPACK, LOW PROFILE, FINE PITCH

• Seated Height-Max:

  1.6 mm

• Supply Voltage-Max:

  3.465 V

• Supply Voltage-Min:

  3.135 V

• Supply Voltage-Nom:

  3.3 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  COMMERCIAL

• Terminal Form:

  GULL WING

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  QUAD

• Width:

  7 mm

• uPs/uCs/Peripheral ICs Type:

  SERIAL IO/COMMUNICATION CONTROLLER, SERIAL
