DMHC10H170SFJ-13 footprint, schematic symbol and 3D model by Diodes Incorporated

Symbol

click to zoom

PCB Footprints

DMHC10H170SFJ-13 - Diodes Incorporated PCB footprint - Other - Other - V-DFN5045-12_2024-6

click to zoom

3D Models

DMHC10H170SFJ-13 - Diodes Incorporated - 3D model - Other - V-DFN5045-12_2024-6

click to zoom

Datasheet Download Datasheet
Stock & Prices Price & Stock for DMHC10H170SFJ-13
Part Number DMHC10H170SFJ-13
Manufacturer Diodes Incorporated
Pin Count 16
Part Category MOSFET Pair (N/P-Channel)
Package Category Other
Footprint Name Other - V-DFN5045-12_2024-6
Released Date Dec 26, 2024
Last Modified Date Dec 26, 2024 3:04 PM UTC
Pinout / Pin List Click Here (Member Only)

DMHC10H170SFJ-13 Details

Manufacturer Part Number:
DMHC10H170SFJ-13
Rohs Code:
Yes
Part Life Cycle Code:
Active
Package Description:
V-DFN5045-12, 12 PIN
Country Of Origin:
Mainland China
ECCN Code:
EAR99
Factory Lead Time:
12 Weeks
Manufacturer:
Diodes Incorporated
YTEOL:
6
Additional Feature:
HIGH RELIABILITY
Case Connection:
DRAIN
Configuration:
2 BANKS, COMMON DRAIN, 2 ELEMENTS WITH BUILT-IN DIODE
DS Breakdown Voltage-Min:
100 V
Drain Current-Max (ID):
2.9 A
Drain-source On Resistance-Max:
0.3 Ω
FET Technology:
METAL-OXIDE SEMICONDUCTOR
JESD-30 Code:
R-PDSO-N12
JESD-609 Code:
e3
Moisture Sensitivity Level:
1
Number of Elements:
2
Number of Terminals:
12
Operating Mode:
ENHANCEMENT MODE
Operating Temperature-Max:
150 °C
Operating Temperature-Min:
-55 °C
Package Body Material:
PLASTIC/EPOXY
Package Shape:
RECTANGULAR
Package Style:
SMALL OUTLINE
Peak Reflow Temperature (Cel):
260
Polarity/Channel Type:
N-CHANNEL AND P-CHANNEL
Power Dissipation-Max (Abs):
2.1 W
Pulsed Drain Current-Max (IDM):
13 A
Reference Standard:
AEC-Q101
Surface Mount:
YES
Terminal Finish:
Matte Tin (Sn)
Terminal Form:
NO LEAD
Terminal Position:
DUAL
Transistor Application:
SWITCHING
Transistor Element Material:
SILICON

DMHC10H170SFJ-13 Frequently Asked Questions (FAQs)

The recommended PCB footprint for the DMHC10H170SFJ-13 is a standard SOT23-6 package with a 1.8mm x 1.35mm body size. The datasheet provides a recommended land pattern and soldering guidelines.
To ensure proper soldering, follow the recommended soldering temperature profile and use a solder with a melting point between 217°C to 227°C. Also, ensure the PCB is clean and free of oxidation.
The DMHC10H170SFJ-13 has an operating temperature range of -40°C to 150°C. However, the device's performance and reliability may degrade if operated at the extreme ends of this range.
Yes, the DMHC10H170SFJ-13 is AEC-Q101 qualified, making it suitable for automotive and high-reliability applications. However, it's essential to follow the recommended operating conditions and design guidelines to ensure the device meets the required reliability standards.
To prevent electrostatic discharge (ESD) damage, handle the DMHC10H170SFJ-13 with an ESD wrist strap or mat, and ensure the workspace is ESD-protected. Also, avoid touching the device's pins or handling it in a way that could generate static electricity.
