DMHT3006LFJ-13 - Diodes Incorporated

DMHT3006LFJ-13 Details

• Manufacturer Part Number:

  DMHT3006LFJ-13

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  V-DFN5045-12, 10 PIN

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• HTS Code:

  8541.29.00.95

• Factory Lead Time:

  12 Weeks

• Date Of Intro:

  2018-09-28

• Manufacturer:

  Diodes Incorporated

• YTEOL:

  7

• Case Connection:

  DRAIN

• Configuration:

  BRIDGE, 4 ELEMENTS WITH BUILT-IN DIODE

• DS Breakdown Voltage-Min:

  30 V

• Drain Current-Max (ID):

  13 A

• Drain-source On Resistance-Max:

  0.01 Ω

• FET Technology:

  METAL-OXIDE SEMICONDUCTOR

• Feedback Cap-Max (Crss):

  80 pF

• JESD-30 Code:

  R-PDSO-N10

• JESD-609 Code:

  e4

• Moisture Sensitivity Level:

  1

• Number of Elements:

  4

• Number of Terminals:

  10

• Operating Mode:

  ENHANCEMENT MODE

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Peak Reflow Temperature (Cel):

  260

• Polarity/Channel Type:

  N-CHANNEL

• Power Dissipation Ambient-Max:

  13 W

• Power Dissipation-Max (Abs):

  2.1 W

• Surface Mount:

  YES

• Terminal Finish:

  NICKEL PALLADIUM GOLD

• Terminal Form:

  NO LEAD

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  30

• Transistor Application:

  SWITCHING

• Transistor Element Material:

  SILICON
