DMN62D0UDW-7 - Diodes Incorporated

Description: MOSFET N-Ch Enh Mode FET 60V 20Vgss 1.2A

Download DMN62D0UDW-7 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
DMN62D0UDW-7 - Diodes Incorporated PCB footprint - SOT23 (6-Pin) - SOT23 (6-Pin) - DMN62D0UDW-7
click to zoom
3D Models
DMN62D0UDW-7 - Diodes Incorporated  - 3D model - SOT23 (6-Pin) - DMN62D0UDW-7
click to zoom

DMN62D0UDW-7 Details

  • Manufacturer Part Number:

    DMN62D0UDW-7

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Country Of Origin:

    Mainland China

  • ECCN Code:

    EAR99

  • Factory Lead Time:

    12 Weeks

  • Manufacturer:

    Diodes Incorporated

  • YTEOL:

    6

  • Additional Feature:

    HIGH RELIABILITY

  • Configuration:

    SEPARATE, 2 ELEMENTS WITH BUILT-IN DIODE

  • DS Breakdown Voltage-Min:

    60 V

  • Drain Current-Max (ID):

    0.35 A

  • Drain-source On Resistance-Max:

    2 Ω

  • FET Technology:

    METAL-OXIDE SEMICONDUCTOR

  • JESD-30 Code:

    R-PDSO-G6

  • JESD-609 Code:

    e3

  • Moisture Sensitivity Level:

    1

  • Number of Elements:

    2

  • Number of Terminals:

    6

  • Operating Mode:

    ENHANCEMENT MODE

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE

  • Peak Reflow Temperature (Cel):

    260

  • Polarity/Channel Type:

    N-CHANNEL

  • Reference Standard:

    AEC-Q101

  • Surface Mount:

    YES

  • Terminal Finish:

    Matte Tin (Sn)

  • Terminal Form:

    GULL WING

  • Terminal Position:

    DUAL

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Transistor Application:

    SWITCHING

  • Transistor Element Material:

    SILICON

DMN62D0UDW-7 Frequently Asked Questions (FAQs)

  • The maximum operating temperature range for the DMN62D0UDW-7 is -55°C to 150°C.
  • Yes, the DMN62D0UDW-7 is suitable for high-frequency switching applications due to its low capacitance and high switching speed.
  • The maximum voltage rating for the DMN62D0UDW-7 is 20V.
  • No, the DMN62D0UDW-7 is not a low-dropout regulator. It is a dual N-channel enhancement mode field-effect transistor.
  • The typical on-state resistance of the DMN62D0UDW-7 is 12 ohms.
