DRA780BDGABFRQ1 - Texas Instruments

DRA780BDGABFRQ1 Details

• Manufacturer Part Number:

  DRA780BDGABFRQ1

• Brand Name:

  Texas Instruments

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  3A991.A.1

• HTS Code:

  8542.31.00.35

• Date Of Intro:

  2017-08-12

• Manufacturer:

  Texas Instruments

• YTEOL:

  15

• Bus Compatibility:

  CAN; I2C; SPI; UART

• Clock Frequency-Max:

  32 MHz

• External Data Bus Width:

  48

• JESD-30 Code:

  S-PBGA-B367

• JESD-609 Code:

  e1

• Length:

  15 mm

• Moisture Sensitivity Level:

  3

• Number of Terminals:

  367

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  BGA

• Package Shape:

  SQUARE

• Package Style:

  GRID ARRAY

• Peak Reflow Temperature (Cel):

  250

• Screening Level:

  AEC-Q100

• Seated Height-Max:

  2.82 mm

• Supply Voltage-Max:

  1.11 V

• Supply Voltage-Min:

  1.02 V

• Supply Voltage-Nom:

  1.06 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  AUTOMOTIVE

• Terminal Finish:

  Tin/Silver/Copper (Sn/Ag/Cu)

• Terminal Form:

  BALL

• Terminal Pitch:

  0.65 mm

• Terminal Position:

  BOTTOM

• Time@Peak Reflow Temperature-Max (s):

  30

• Width:

  15 mm

• uPs/uCs/Peripheral ICs Type:

  SoC
